| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | August 2000 |
| Software Available | October 2000 |
| Date Tested | September 2000 |
| SFS License Number | 33 |
| Licensee Locations | Sunnyvale, CA |
| CPU, Memory and Power |
|---|
| Model Name | F840 Scalable Storage Network Cluster (6-node, non-failover, UDP, 168x18GB FCAL, 6xGbE) |
| Processor | 733-MHz Intel Pentium III Coppermine |
| # of Processors | 6 (1 per node) |
| Primary Cache | 16 KB I + 16 KB D |
| Secondary Cache | 256 KB on-die |
| Other Cache | n/a |
| UPS | none |
| Other Hardware | none |
| Memory Size | 18432 MB (3072 MB per node) |
| NVRAM Size | 768 MB (128 MB per node) |
| NVRAM Type | DIMMs on PCI cards |
| NVRAM Description | 15-day battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | Data ONTAP 5.3.7 |
| Other Software | none |
| File System | WAFL |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | default |
| # NFS Processes | N/A |
| Fileset Size | 881.9 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | X1025B PCI adapter card |
| Number Networks | 1 (N1) |
| Number Network Controllers | 6 (1 per node) |
| Protocol Type | UDP |
| Switch Type | Foundry Networks: 3 FastIrons, 1 BigIron |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 12 |
| Number of Disks | 168 (24 7-bay JBOD shelves) |
| Number of Filesystems | 6 |
| File System Creation Ops | default (checksum_blocks=on) |
| File System Config | 1 RAID-group of 27 disks |
| Disk Controller | X2040B FC-AL adapter card (128 KB RAM standard) |
| # of Controller Type | 12 |
| Number of Disks | 168 (14 per controller) |
| Disk Type | X221 18GB FC-AL |
| File Systems on Disks | F1-F6 |
| Special Config Notes | none |
|
