| Server Configuration and Availability |
|---|
| Vendor | Traakan, Inc. |
| Hardware Available | January 2001 |
| Software Available | January 2001 |
| Date Tested | October 2000 |
| SFS License Number | 1730 |
| Licensee Locations | Los Altos, CA |
| CPU, Memory and Power |
|---|
| Model Name | FT450L |
| Processor | Intel Celeron 600E |
| # of Processors | 1 |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 128KB(I+D) on chip |
| Other Cache | na |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 512 MB |
| NVRAM Size | N/A |
| NVRAM Type | N/A |
| NVRAM Description | N/A |
| Server Software |
|---|
| OS Name and Version | Fastraak 1.0 |
| Other Software | N/A |
| File System | Fastraak SFS2 |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | 40 |
| Fileset Size | 19.3 GB |
|
| Network Subsystem |
|---|
| Network Type | 100BT Ethernet |
| Network Controller Desc. | Intel 82559 10/100 Chip |
| Number Networks | 1 (N1) |
| Number Network Controllers | 1 |
| Protocol Type | UDP |
| Switch Type | Hewlett Packard ProCurve 4000M |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 4 |
| Number of Disks | 4 |
| Number of Filesystems | 4 plus HOST OS File System |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | IDE (440BX chipset) |
| # of Controller Type | 2 |
| Number of Disks | 2 |
| Disk Type | IBM DTLA-307075, 76.8GB IDE |
| File Systems on Disks | F1-2, Host OS (200 MB) F5 |
| Special Config Notes | F1 and F5 on 1 Disk, 1 Disk per Controller |
| Disk Controller | Abit Hot Rod 100 Pro, Dual IDE Controller |
| # of Controller Type | 2 |
| Number of Disks | 2 |
| Disk Type | IBM DTLA-307075, 76.8GB IDE |
| File Systems on Disks | F3-4 |
| Special Config Notes | 1 Disk Per Controller |
|
