| Server Configuration and Availability |
|---|
| Vendor | EMC Corporation |
| Hardware Available | February 2001 |
| Software Available | February 2001 |
| Date Tested | November 2000 |
| SFS License Number | 00047 |
| Licensee Locations | Westboro, MA |
| CPU, Memory and Power |
|---|
| Model Name | EMC CLARiiON IP4700, Cluster (UDP, GbE) |
| Processor | 733 MHz Intel |
| # of Processors | 2 (1 per SP) |
| Primary Cache | 16KBI+16KBD on chip |
| Secondary Cache | 256KB |
| Other Cache | N/A |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 1.5 GB (750 MB per SP) |
| NVRAM Size | 500 MB (250 MB per SP mirrored Write Cache) |
| NVRAM Type | ECC Protected RIMMs |
| NVRAM Description | Battery backup with storage on RAID-3 disk group |
| Server Software |
|---|
| OS Name and Version | StackOS HA 1.1 |
| Other Software | N/A |
| File System | HTFS |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | N/A |
| Fileset Size | 117.0 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | Alteon ACEnic PCI Rev C |
| Number Networks | 1 (N1) |
| Number Network Controllers | 2 (1 per SP) |
| Protocol Type | UDP |
| Switch Type | 3COM Super Stack II Switch 9300 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 2 (1 per SP) |
| Number of Disks | 100 |
| Number of Filesystems | 18 (A1-A9,B1-B9) |
| File System Creation Ops | default |
| File System Config | default |
| Disk Controller | IP4700 RAID Processor |
| # of Controller Type | 1 |
| Number of Disks | 55 |
| Disk Type | Seagate ST336704 36GB 10000rpm |
| File Systems on Disks | A1-A9 (45 disks) |
| Special Config Notes | See Other Notes |
| Disk Controller | IP4700 RAID Processor |
| # of Controller Type | 1 |
| Number of Disks | 55 |
| Disk Type | Seagate ST336704 36GB 10000rpm |
| File Systems on Disks | B1-B9 (45 disks) |
| Special Config Notes | See Other Notes |
|
