| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | December 2000 |
| Software Available | December 2000 |
| Date Tested | January 2001 |
| SFS License Number | 33 |
| Licensee Locations | Sunnyvale, CA |
| CPU, Memory and Power |
|---|
| Model Name | NetApp F740 Failover Cluster (UDP, 28x36GB FCAL, 2xGbE) |
| Processor | 400MHz Alpha 21164A |
| # of Processors | 2 (1 per node) |
| Primary Cache | 8 KB I + 8 KB D on-chip |
| Secondary Cache | 96 KB (I+D) on-chip |
| Other Cache | 1 MB (I+D) off-chip per node |
| UPS | none |
| Other Hardware | X1901B cluster interconnect (see notes) |
| Memory Size | 1024 MB (512 MB per node) |
| NVRAM Size | 64 MB (32 MB per node) |
| NVRAM Type | SIMMs on PCI cards |
| NVRAM Description | 6-month battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | Data ONTAP 6.0.1R1 |
| Other Software | Cluster Option |
| File System | WAFL |
| NFS version | 3 |
| Server Tuning |
|---|
| Buffer Cache Size | default |
| # NFS Processes | N/A |
| Fileset Size | 71.4 GB |
|
| Network Subsystem |
|---|
| Network Type | Gigabit Ethernet |
| Network Controller Desc. | X1025B PCI adapter card |
| Number Networks | 1 (N1) |
| Number Network Controllers | 2 (1 per node) |
| Protocol Type | UDP |
| Switch Type | Extreme Summit4 |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | N/A |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 4 |
| Number of Disks | 28 |
| Number of Filesystems | 2 |
| File System Creation Ops | default |
| File System Config | 1 RAID-group, 13 disks |
| Disk Controller | X2030B FC-AL adapter card (64 KB RAM standard) |
| # of Controller Type | 4 |
| Number of Disks | 7,7/7,7 |
| Disk Type | X231A 36GB 10000RPM FC-AL |
| File Systems on Disks | F1/F2 |
| Special Config Notes | 2 primary controllers, 2 secondaries (see notes) |
|
