| Server Configuration and Availability |
|---|
| Vendor | Network Appliance, Inc. |
| Hardware Available | March 1998 |
| Software Available | March 1998 |
| Date Tested | January 1998 |
| SFS License Number | 33 |
| Licensee Locations | Santa Clara, CA |
| CPU, Memory and Power |
|---|
| Model Name | NetApp F630 (UDP, 28x9GB FCAL, FDDI) |
| Processor | 500MHz Alpha 21164A |
| # of Processors | 1 |
| Primary Cache | 8KBI+8KBD on chip |
| Secondary Cache | 96KB(I+D) on chip |
| Other Cache | 2MB(I+D) off chip |
| UPS | N/A |
| Other Hardware | N/A |
| Memory Size | 512MB |
| NVRAM Size | 32MB |
| NVRAM Type | NVRAM SIMMs on PCI card |
| NVRAM Description | 6-month battery-backed shelf-life |
| Server Software |
|---|
| OS Name and Version | NetApp OS version 5.0 beta2 |
| Other Software | N/A |
| File System | WAFL |
| NFS version | 2 |
| Server Tuning |
|---|
| Buffer Cache Size | Dynamic |
| # NFS Processes | see notes |
| Fileset Size | 48.3 GB |
|
| Network Subsystem |
|---|
| Network Type | FDDI |
| Network Controller Desc. | x1102 (SA TP) MLT3 FDDI Adaptor |
| Number Networks | 2 (N1-N2) |
| Number Network Controllers | 2 |
| Protocol Type | UDP |
| Switch Type | N/A |
| Bridge Type | N/A |
| Hub Type | N/A |
| Other Network Hardware | DEC Concentrator |
| Disk Subsystem and Filesystems |
|---|
| Number Disk Controllers | 1 |
| Number of Disks | 28 |
| Number of Filesystems | 1 |
| File System Creation Ops | default |
| File System Config | two RAID groups of 14 disks each |
| Disk Controller | |
| # of Controller Type | |
| Number of Disks | |
| Disk Type | |
| File Systems on Disks | |
| Special Config Notes | |
| Disk Controller | FibreChannel Card, QLA 2100 |
| # of Controller Type | 1 |
| Number of Disks | 28 (4x7-disk JBOD shelves) |
| Disk Type | 9GB Seagate Barracuda (ST19171FC) |
| File Systems on Disks | F1 |
| Special Config Notes | none |
|
